MODEL: EHTS17X

EHTS Series Stationary Three Phase Industrial Vacuum Cleaner for Production Lines

ENDUSTMAN EHTS17X is a compact stationary three phase vacuum for production lines and laser machines. The 1750W blower runs continuously, and the 35L quick-release tank makes waste handling easy.

Key Options	Value
Power	1750 W
Voltage / Phase	StandardThree-Phase, 380V@50Hz Optional380V / 400V / 415V / 460V / 480V, @50Hz / 60Hz NoticeVoltage and frequency can be configured according to local power supply requirements. CustomizationCustom voltage options are available upon request. Please specify your local voltage and frequency when ordering.
Airflow	270 m³/h^{What is this?}
Vacuum / Suction	21 kPa^{What is this?}
Tank Capacity	35 L^{What is this?}

Get A QuoteNeed Customization

Specifications

Options	Value
Inlet Diameter	40 mm
Filter Cleaning	Manual Back-flush ^{What is this?}
Noise	64 dB(A) ^{What is this?}
Filter Area	25000 cm² ^{What is this?}
Weight	60 kg
Dimensions	950 × 420 × 780 mm
MOQ	No Minimum order required
Shipping	Global Delivery, Customs clearance supported
Warranty	1-year warranty with responsive after-sales support.
Key application	Equipment integration and stationary use beside machines; light dust loads; budget-sensitive applications.

Accessories

Standard 40mm Accessory Kit

5 m nylon hose (40mm inner diameter, quick-connect);
Floor nozzle for dry pickup;
Squeegee nozzle for water pickup;
Round brush for delicate surfaces;
Crevice tool for narrow gaps;
Two stainless steel wands — connectable into one long tube.

See all accessories, hose & power supply options →

Description

The EHTS series is a simplified stationary three-phase industrial vacuum cleaner with an open, housing-free frame designed for continuous duty. It is built for equipment integration, production lines, and fixed work areas, and pairs easily with laser marking machines, engraving machines, and food or pharmaceutical production lines. A side-channel high-pressure blower delivers powerful, stable suction and is rated for long continuous operation, while custom electrical components ensure safe, reliable control. The washable laminated filter provides high filtration precision, and the quick-release up-and-down tank makes waste disposal fast. Standard 380V power with a 220V option, 40mm accessories included, and 50mm accessories or casters available on request.

Key Features

Standard 380V power supply, 220V optional;
Side-channel high-pressure blower with strong suction, rated for long continuous operation;
Custom electrical components for safe and reliable control;
Washable laminated filter element with higher filtration precision;
Quick-connect suction inlet for fast and easy use;
Quick-release up-and-down tank design for convenient waste disposal;
Standard 40mm accessories, 50mm accessories optional;
Simple stationary design, casters available on request.
